Designed for the next generation of Digital Cinema, the Qube Xi Integrated Media Block (IMB) is designed to seamlessly integrate into any Series 2 DLP Cinema™ projector and work in 2K and 4K resolutions.
Qube Xi
- 2K and 4K resolution, software upgradable from 2K to 4K
- FPGA-based JEPG2000 decoding to deliver stunning 4K images
- Dual-Redundant Gigabit Ethernet connections
- Stereoscopic 3D playback with all available technologies
- Optional 48 fps and 60 fps HFR 3D
- Quad 3 Gbps HDSDI for 4K, 2K, HD and 3D uncompressed input
- Multi-IMB sync for dual-projector 3D and quad-projector 3D
- Autonomous IMB for standalone operation without storage server
Qube XP-I
- Storage server for the Qube Xi Integrated Media Block
- 4 to 8 TB of RAID Storage with hot-swap drive bays
- QubeTouch Web App and Android App for simple, powerful remote operation
- Plays to dual-projectors at up to 1,000 Mbps from one DCP, 4x the DCI spec
Qube Xi Integrated Media Block Technical Specifications
| Image Formats | DCI JPEG2000, MPEG-2 4:2:0 & 4:2:2 |
| Image Resolutions | 2048x1080 2D @24, 25, 30, 50, 60, 96, 100, 120 fps 2048x1080 3D @24, 48, 60 fps optional 4096x2160 2D @ 24, 25, 30 fps |
| Stereoscopic 3D Systems | Master Image and XpanD optional Real-D™ and Dolby 3D™ support |
| Audio Formats | Linear PCM Audio, 48 KHz and 96 KHz, 24-bit |
| Subtitling | TI CineCanvas™ & SMPTE formats Internal & Projector rendering |
| I/O Ports | Gigabit Ethernet Port, RJ-45 x 2 USB 2.0 Ports x 2 AES3 Digital Audio Outputs, RJ-45 x 2 optional Sync In & Sync Out, BNC x 2 optional 3Gbps HDSDI inputs, BNC x 4 option Linear Timecode Out, BNC x 1 |
| Forensic Watermarking | Civolution NexGuard™ |
| Physical Dimensions | Height 3.5" (89mm) Width 16.8" (426mm) Depth 25.6" (650mm) |
| Specifications mentioned herein are subject to change without notice due to continuous product development | |
QubeTouch is an intuitive new user interface that will work with all Qube Digital Cinema Servers. QubeTouch is available as a touch-enabled HTML5 web app built into the Qube Server and accessible on any modern web browser including those on the iPad and other tablets; and also as an Android application called QubeTouch Remote that will soon be available on the Google Play app store, free for a limited time.
The QubeTouch interface provides theatre managers and projectionists with a consistent, highly interactive user experience on both the desktop (web interface) and the mobile (Android app) worlds. And because QubeTouch is a standards based platform, a dedicated management system or a proprietary touch panel is not required, in turn ensuring minimum expenditure and maximum productivity.
The feature set is extensive, providing convenient access to everyday functions such as basic show & playback controls, as well as advanced health monitoring and usage information. Intuitive dialogs, familiar action icons & buttons, enable the user to manage media and keys, setup automatic show schedules, adjust system configuration settings, and more.
QubeTouch Android App
QubeTouch Web App
